· Masonry types Types and grouping of masonry units. Types of mortars and specifications · Mechanical properties of Masonry Compressive, flexural and shear strength. Modulus of Elasticity. Walls under compressive and/ or later loads. · Structural elements of buildings Types of floors and sills. Types, function, failure and strengthening measures of arches, vaults and domes · Types and vulnerability of existing buildings frequent found in Greece Classification of building stock and relation between structural type and vulnerability · Plain, Confined and Reinforced masonry. Specifications according to EN 1996 and EN 1998 • Design of masonry according to Eurocode 6 Unreinforced and reinforced masonry walls under compressive or/and in-plane or out-of-plane loading • Analysis methods and seismic behavior of masonry buildings The available methods for the analysis of masonry structures are examined and their ability to predict the seismic behavior of existing structures is verified by comparing the results with the developed seismic damage. • Damage of masonry structures Damage generated of structural faults as well as of soil effects. Seismic vulnerability of masonry structures • Strengthening techniques Fields of application and execution of techniques like repointing, grouting, and sprayed concrete. Structural details for the construction of horizontal diaphragms and insertion of tendons. • Repairs and Strengthening of existing masonry structures Details on the selection and execution of the proper repairing or retrofitting works depending on the type of damage and masonry type • Effectiveness and cost of strengthening measures Effectiveness criterion, effectiveness and relation with the cost of retrofitting measures
|
DESIGN AND REPAIR OF MASONRY STRUCTURES
SEMESTER | 8th or 10th |
---|---|
eclass | https://eclass.upatras.gr/courses/CIV1521/ |
Details | https://www.civil.upatras.gr/index.php/odhgos/ |
LANGUAGE OF INSTRUCTION and EXAMINATIONS | Greek |
Credits ECTS | 5 |
Teaching Hours | 3 |
Erasmus+ | no |
Code | CIV_8268Α |
The scope of the course is the comprehension of :
a) The materials and the types of structural masonry and their effect to the mechanical properties of masonry b) The specifications for the design of new structures of plain, confined and reinforced masonry according to Eurocodes c) The design principles for new masonry structures in seismic areas d) The verification of unreinforced and reinforced masonry walls under compressive and lateral loads e) The verification of masonry buildings under seismic loads f) The pathology of masonry structures, focused on the seismic vulnerability g) The knowledge of available repair and strengthening techniques as well as criteria for the selection of strengthening measures based on technical and social data h) The proper selection for the repairing and strengthening of damaged or vulnerable buildings After completed this course the student will be able to: a) calculate the mechanical properties of an existing or new masonry b) choose the proper materials for structural masonry in seismic areas c) estimate the vulnerability of existing masonry buildings frequent found in Greece d) design a building according to the specifications of Eurocodes 6 and 8 e) execute a complete seismic verification of an existing masonry building f) give an explanation of any damage of a masonry structure g) choose the proper repairing or strengthening measure for the retrofitting of an existing masonry building
|
